Your Position:>Products> DC Trigger Switch with Speed Control with protection against dust> FA01-15/1WEK FA01-20/1WEK
Name: FA01-20/1WEK-BX8-A02-Z7-F1-S11
Order Info
Description:

Product description

SPNO with integrated PWM (Pulse Width Modulated) electronics in various dimen-Sions optional with:

Integrated reversing module
Lock-off in mod-position of lever
Integrated brake contact
Protection against dust
Trigger covered with rubber
MOSFET inside with heat sink
MOSFET outside with heat sink
Wire for LED outside

Average duty cycle of motor voltage 8 - 60% to 8 - 90% (according to client's demand), then by-pass to battery voltage

Technical data
Electrical rating mechanical  contact System SPNO
25A  7.2-36VDC / 20A  36VDC

Certificated rating
FA01-25/1WEK
   25A  7.2-36VDC
FA01-20/1WEK   FA01-20/1WEK
   20A  7.2-36VDC          20A  36VDC
FA01-15/1WEK   FA01-12/1WEK
   15A  7.2-36VDC    12A  36VDC

Terminals
 Line side:
Solder terminal  4.8/6.30.8mm
Motor side:
Solder terminal  4.81.0mm
The product has obtained a Chinese national Certificate of Utility Model Patent
