产品描述Product description
◆MK07系列是一款专用型线路板组件,具有软启动,恒转速等功能,广泛应用于各类手持式电动工具,如: 150和180角向磨光机，拋光机等.
◆MK07 series are one special type PCB Assembly, with soft start function and Constant Speed function, etc. Commonly for used in portable power-tools such as 150mm and 180mm Angle Grinders, Polisher Grinders, etc.
产品特征Features
◆可选带以下功能Optional following function types:
→断电重启保护功能Restart Protection(X)
→电子调速功能Electronics Speed Control Function(E)
→软启动功能Soft Start Function(S)
→恒转速功能Constant Speed function(CS)
→恒功功能Constant Power Function(P)
→过流保护功能Over Current Protection Function(CP)
技术数据Technical data
→电气耐久寿命Electrical life endurance≥5E4
→最大电流Max. current at 250V12A
→最大电流Max. current at 127V18A
→绝缘电阻Insulation resistance≥7M Ohm
→基本介电强度Dielectric strength of function500V
→加强介电强度Dielectric strength of reinforced3000V
→环境温度Ambient temperature0°C~55°C
→阻燃等级FlammabilityUL 94V-0
→适用于II类防护器具Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端Input side/Output side:
→导线端子Wire lead terminals
→信号端-带插头导线Single-Wire lead terminals with plug
电气参数和认证 Electric Rating and Certification
