产品描述Product description
◆RSA, RSB, RSC系列是一款通用型的旋转开关，广泛应用于各类需要档位选择的家用电器，如：电炖锅、食物搅拌机、榨汁机、豆浆机、吸尘器、电风扇、空调扇、台灯等。开关有多种转轴和外壳可以选择，也可以根据客户要求进行定制，也可以应用于一些特殊的电动工具和园林工具，如：热风枪、吹风机等。
◆RSA, RSB, RSC series are general type rotary switches, for popular used in home appliances such as: Slower Cookers, Food Mixers, Full Automatic Soya-bean Milk Machines, Juicers, Vacuum Cleaner, Electric Fan, Air Condition Fan, Table Lamps, etc. Also for used in some special Power-tools and Gardening tools, such as: Heat Guns, Electric Blowers, etc.
产品特征Features
◆可选带以下功能 Optional with function as follows:
→单极两档位 Single Pole 2 Position
→单极三档位 Single Pole 3 Position
→单极四档位 Single Pole 4 Position
→单极五档位 Single Pole 5 Position
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4
→电气耐久寿命 Electrical life endurance≥1E4
→最大冲击电流 Max. Inrush current at 250V18A
→最大冲击电流 Max. Inrush current at 125V18A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~125°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→4×插入式端子可插入沾锡导线、带插片端子导线或铜包头导线
→4×Push-in terminals for soldered strands, strands with end sleeves or strands with end claws.
电气参数和认证 Electric Rating and Certification
