JB01B-2110-K1

JB01/JB01B(防尘防水)安全开关

JB01/JB01B series (Dustproof and Waterproof) Safety Switch

产品描述Product description

JB01系列是一款大电流的安全限位开关,集成防尘防水功能JB010B为迷你款,适用于各类台式电动工具和园林工具,如:台式推拉锯、台式圆锯、台式刨床、台式铣床、台式车床、台式线锯、台式钻床和家用碎枝机等。
JB01 series are high rated safety limited switches, integrated dustproof and waterproof, JB010B is mini-type, for used in bench top power-tools or gardening tools, such as Bench Push-pull Saws, Bench Circular Saws, Bench Planers, Bench Routers, Bench Lathes, Bench Scroll Saws, Bench Drill Presses, Domestic Shredders, etc.

产品特征Features

◆可选带以下功能 Optional with the function as follows:
→双极常开 DPNO (Double Pole Normally Open)
→双极常闭 DPNC (Double Pole Normally Close)
◆可选带以下附件 Optional with the accessories as follows:
→钥匙扣 Key
→门控制杆 Handle for door

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥5E4 / 1E5
→电气耐久寿命 Electrical life endurance≥1E4 / 5E4
→最大冲击电流 Max. Inrush current at 250V90A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP54 Max.
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆JB01输入端/输出端 Input side/Output side of JB01:
→螺钉端子 Screw terminals M4
◆JB01B输入端/输出端 Input side/Output side of JB01B:
→插片端子 Plug-in terminals 4.8×4.8mm

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
